《注文方法》
① 使う圧力, Tube Sizeに当たる Female 1 選択(表意縦参照).
② 連結する圧力, Tube Sizeを確認後 Female 2 選択(表意横参照).
③ 当たる Catalog Noと寸法を確認.
(単位 : mm)
Pressure Rating
15,000 psi
(Female 2)
15,000 psi
(Female 1)
Catalog No. / Dimensions
A
B
A
B
A
B
A
B
Tube Size
(Port Type)
1/8"
(H1502)
1/4"
(H1504)
3/8"
(H1506)
1/2"
(H1008)
1/8"
(H1502)
A015F2/015F2-B
25.4
53.9
1/4"
(H1504)
A015F4/015F4-B
25.4
53.9
3/8"
(H1506)
A015F6/015F6-B
34.9
60.3
1/2"
(H1008)
A010F8/015F6-B
38.1
60.3
